Scaling & Feature Licenses

Expanded software-based functionality

Expand functionality at the software-level

Anticipate changing requirements and leverage additional features via simple license activations, powered by the Q-SYS Intelligent Platform OS. Q-SYS Scaling Licenses offer expanded functionality in alignment with your specific installation requirements, while Q-SYS Feature Licenses enable additional features on Q-SYS Products, letting you design your Q-SYS system to the unique needs of each space.


Q-SYS Scaling Licenses

Image of people watching a screen in a classroom

Q-SYS Core Nano & Core 8 Flex Capacity Scaling License

Enable your Core Nano or Core 8 Flex processors to scale into areas that require increased processing power, total network channel capacity and peripheral count . It also expands the resources aimed at meeting spaces or BGM/paging applications, including AEC channel, NM Series microphone capacity, softphones, and Media / WAN streaming capacity.

Image of Q-SYS hardware

Q-SYS Core 610 Scaling License

Expand the capabilities of the Q-SYS Core 610 at the software level, whether before installation or as business needs change. Increases the overall power of the processor, increasing capacity for total network channels, Media/WAN streaming channels, AEC channels and Q-SYS NM Series microphone capacity.

Q-SYS Feature Licenses

Image of computer and tablet displays in a conference room

Q-SYS AV Bridging Feature License

Expand the functionality of the TSC Series Gen 3 network touchscreens to allow users to connect their device directly via USB to easily integrate Q-SYS audio and camera feeds for remote meetings.

Image of people sitting around conference room table

Q-SYS NV-32-H Core Mode Streaming Feature License

Expand the NV Series NV-32-H (Core Capable) to offer simultaneous functionality for Q-SYS Core processing and network video encoding or decoding, streamlining installations while lowering product and installation costs.

Image of software displayed on computer screen

Software Based Dante Feature License for the Q-SYS Platform

Integrate Dante network audio into the Q-SYS Intelligent Platform OS.

Q-SYS Control

Feature licenses are no longer required to leverage Q-SYS Control capabilities on systems running Q-SYS Designer v10 or above. For systems that need to run Q-SYS Designer v9.x or lower, you will still need to deploy a free feature license, available here.

                     Q-SYS SCALING LICENSES

 Features Q-SYS Core Nano & Core 8 Flex Capacity Scaling License Q-SYS Core 610 Scaling License
Part Number SLCS20-8N-P SLCS15-610-P
Applicable Hardware Core Nano, Core 8 Flex Q-SYS Core 610
Type Perpetual, Node Locked Perpetual, Node Locked
Supported QDS Version v10.0 or higher v9.9 or higher
Q-LAN/AES67 network channels 128 x 128 (2x from standard) 384 x 384 (1.5x from standard)
Additional DSP processing power Approx. 2x from standard Approx. 1.5x from standard
Softphones 4 (2x from standard) -
AEC Processors @ 200 ms 16 (2x from standard) 96 (1.5x from standard)
Additional NM-T1 Support Up to 6 (2x from standard) 24 (1.5x from standard)
Media/WAN network channels Increased to 24 x 24 (2x from standard) 96 x 96 (1.5x from standard)
Q-SYS peripheral count Increased to 48 (1.5x from standard) -



All specifications are subject to change without notice.

                     Q-SYS FEATURE LICENSES

Q-SYS Audio

License Type Part Number Applicable
Hardware		 Type Supported
Q-SYS Designer
Software Version		 Description
Software-Based
Dante		 SLDAN-8-P All Q-SYS Cores Perpetual,
Node Locked		 v9.01 or higher 8x8-channels.
This license is included on all Q-SYS Cores except the NV-32-H.
It can be purchased for an NV-32-H, or for a Q-SYS Core 110f sold prior to 30 March, 2020 or Cores 510i and 5200 sold prior to January 1, 2021.
SLDAN-16-P 16x16-channels
SLDAN-32-P 32x32-channels
SLDAN-64-P Core 24f, 510i, 610, 5200, Server Core X10, Server Core X20r 64x64-channels
SLDAN-128-P Core 510i, 610, 5200, Server Core X10, Server Core X20r 128x128-channels
SLDAN-256-P Core 610, 5200, Server Core X20r 256x256-channels
SLDAN-512-P Core 5200 512x512-channels
Multi Track
Playback		 SLMTP-32 Core Nano2,
8 Flex2, 110f2, 24f, 510i2,
610, 5200, Server Core X10, Server Core X20r		 Perpetual,
Node Locked		 v7.0 or higher 32 Audio Player tracks, stackable3



Q-SYS Video

License Type Part Number Applicable Hardware Supported Q-SYS Designer Software Version Description
AV Bridging SLQBR-P TSC-70-G3,
TSC-101-G3		 v9.7 or higher Enables AV Bridging for native Q-SYS devices. One license required PER device with AV Bridging enabled.
Core Mode Streaming SLQCMS-NV32-P NV-32-H (Core Capable) v9.9 or higher Expand the NV Series NV-32-H (Core Capable) to offer simultaneous functionality for Core processing and network video encoding or decoding
  1. Core24f, Server Core X10 and Server Core X20r require v10.0 or higher. For Core 610, Q-SYS Designer v9.9 or later is required to add the SLDAN-256-P license.
  2. Core Nano, 8 Flex, 110f, and 510i require a media drive option installed to deploy expanded multi-track playback capacity.
  3. Stacking requires Q-SYS Designer Software v10.0 or higher.



All specifications are subject to change without notice.
