Immersive cinema sound formats give filmmakers unprecedented creative freedom in the production of the soundtrack. But for the exhibitor, it also places greater demands on the entire sound system—especially the surround loudspeakers and amplifiers. Sound designers want to localize sound with three-dimensional freedom at any volume level, so each individual loudspeaker needs to be capable of producing clean, undistorted sound at levels comparable to a screen channel.

Q-SYS Immersive Sound Features

Icon of a speaker

High Power Surrounds

Q-SYS surround loudspeakers designed for immersive applications produce greater output than conventional surround loudspeakers and they include special safety features like plywood construction and multiple mounting options.

Icon of a Q-SYS control hardware

Q-SYS Control & Monitoring

The Q-SYS platform allows direct control and monitoring of each amplifier channel and loudspeaker.

Icon of a subwoofer

Subwoofers Designed for Safe Installation

For Immersive low-frequency extension, we offer subwoofers that are designed for safe and easy suspension using eight built-in M10 fly points. Heavily braced, tour grade 15 mm plywood construction provides great strength while keeping weight to a minimum.

Icon of an amplifier

Multi-channel power amplifiers

Q-SYS 4- and 8-channel amplifiers provide a cost-effective and space-saving solution for surround loudspeaker amplification.

Alamo Drafthouse DTLA

Q-SYS achieves high standards and integrated solutions for one of America’s leading cinematic experiences.

Example Diagrams

Small

Click image to enlarge

Diagram of a small cinema featuring Q-SYS Hardware and speakers




System Components

1 – Q-SYS Core 110f Processor

1 – Switch

1 – DCIO-H Digital Cinema Input/Output

3 – DCA 1222 Power Amplifier

3 – DCA 3022 Power Amplifier

2 – CX-Q 8-Channel Power Amplifier

1 – CX-Q 4-Channel Power Amplifier

3 – RSC-112 / RSB-212, RBK-12 Reference Monitors

1 – SB-1180 Subwoofers

2 – SB-118F Subwoofers

16 – SR-8200 Surround Loudspeakers


Large

Click image to enlarge

Diagram of a large cinema featuring Q-SYS Hardware and speakers




System Components

1 – Q-SYS Core 110f Processor

1 – Switch

7 – CX-Q 4-Channel Power Amplifier

5 – CX-Q 8-Channel Power Amplifier

5 – SC-433C Screen Channel Loudspeakers

4 – SB-7218 Subwoofers

8 – SR-1590 Surround Loudspeakers

32 – SR-1290 Surround Loudspeakers

4 – SB-218F Subwoofers


X-Large

Click image to enlarge

Diagram of an extra-large cinema featuring Q-SYS Hardware and speakers




System Components

1 – Q-SYS Core 110f Processor

1 – Switch

13 – CX-Q 8-Channel Power Amplifier

5 – SC-444 Screen Channel Loudspeakers

8 – SB-7218 Subwoofers

4 – SB-218F Subwoofers

8 – SR-1590 Surround Loudspeakers

40 – SR-1290 Surround Loudspeakers


PLF

Click image to enlarge

Diagram of a premium large format cinema featuring Q-SYS Hardware and speakers




System Components

1 – Q-SYS Core 110f Processor

1 – Switch

5 – CX-Q 4-Channel Power Amplifier

8 – CX-Q 8-Channel Power Amplifier

5 – SC-444 Screen Channel Loudspeakers

6 – SB-15121 Subwoofers

4 – SB-218F Subwoofers

8 – SR-1590 Surround Loudspeakers

40 – SR-1290 Surround Loudspeakers


Q-SYS SR Series badge

Surround channels create the multidimensional soundscape that puts your audience into the picture. With a range of compact enclosures
that fit every decor, the SR Series cinema surround loudspeakers offers the perfect surround solution for any size theater.
