AD-C6T-LP

6.5-inch, 2-way, low profile, 135° conical DMT™

  • Hero front and side view of the AD-C6T-LP in-ceiling speaker
  • Hero front view of the AD-C6T-LP in-ceiling speaker with and without the speaker grill
  • Hero view of installing and removing the AD-C6T-LP speaker grill
Image of two Acoustic Design Series AD-C4T Speakers

This product has been discontinued. Please check with your Q-SYS regional sales representative for remaining stock availability.

Consider the AD-C6T-LPZB loudspeaker as a replacement:

  • The AD-C6T-LPZB is a 6.5-inch, 2-way, low profile, zero bezel loudspeaker that features consistent tonal characteristics across the AcousticDesign™ series.
Certified for Microsoft Teams badge

Features

  • Consistent tonal characteristics across the entire AcousticDesign™ family in both surface or ceiling applications
  • Directivity Matched Transition® (DMT) waveguide ensures smooth, uniform frequency response over the coverage area
  • Snap-fit magnetic grille
  • 3x double stepped, long travel dog-ear blind mount system
  • Advanced Intrinsic Correction™ voicings available via Q-SYS™
  • Low-saturation and low-loss 70/100V transformers with 16Ω bypass
  • Blemish-free removable logo
  • Removable conduit cover plate, also available as accessory for pre-install wiring
  • UL1480 and UL2043 certified
  • Available in white (RAL 9010)
  • Complete EASE, CF2, CAD, & BIM information available online

SPECIFICATIONS

AD-C6T-LP

Effective frequency range1

65 Hz – 20 kHz

Rated noise power / voltage2

60 watts / 31 volts (rms)

Sensitivity [dB]3

Sensitivity at 4m, 100V maximum tap

88

TBD

Rated coverage (-6 dB)4

135° conical DMT™

Directivity factor (Q)

6.5

Directivity index (DI) [dB]

8

Maximum continuous SPL [dB]5

106

Maximum peak SPL [dB]5

112

Nominal impedance [ohms]

16

Transformer taps / impedance

16Ω (in bypass setting)
7.5W (70V); 15W (100V) Tap: 667Ω
15W (70V); 30W (100V) Tap: 333Ω
30W (70V); 60W (100V) Tap: 167Ω
60W (70V); N/A (100V) Tap: 83Ω

LF transducer

165 mm [6.5-inch] weather resistant paper cone woofer

HF transducer

25 mm [1-inch] aluminum dome tweeter

Input connector type

Euroblock connector with parallel output

Enclosure material

ABS baffle on powder coated steel back can

Grille material

Powder coated steel

Ingress protection

IP-34

Operating environment

Designed for indoor use

Operating temperature range

-20 to 50° C [-4 to 122° F]

Cutout dimension

Ø 305 mm [Ø 12-inch]

Net weight

4.2 kg [9.3 lb]

Product dimensions (Diameter x Height)

Ø 340 x 100 mm [Ø 13.37 x 3.95-inch.]

Shipping weight

13.3 kg [29.3 lb] (pair packed)

Shipping dimensions (H x W x D)

178 x 864 x 470 mm [7 x 34 x 18.5-inch] (pair packed)

Included accessories

C-ring and tile rails, rail screws, euroblock connector, cut-out template, tether grille

Optional accessories

AD-MR8 (pre-install mud ring)

Safety Agency

UL1480, UL2043, NFPA90, NFPA70 suitable for use in air handling spaces. Transformer UL registered per UL1876, ROHS, C-Tick X000, CE compliant. Baffle meets UL94-V0 and UL94-5VB flammability rating; in accordance with IEC60849 / EN60849 systems.
Optional accessories AD-MR8 (pre-install mud ring)



1 Half Space, -10dB from on-axis sensitivity
2IEC60268-5 50hz high passed noise at 2 Hrs, 16Ω
3 Free-field, on-axis, 2.83V, 1m
4-6 dB from on-axis, 500 Hz–5 kHz average
5Calculated from rated noise voltage and sensitivity
